Air Cooled Transformer Rectifier (Stainless Steel Enclosure)
This air-cooled transformer rectifier is a kind of automatic controlled transformer, used as the DC power for impressed current cathodic protection. With the advantages of compact structure and light weight, it is ideal for smaller installations in cleaner environments. Typically, it is widely used for the cathodic protection of long pipelines, tank interior bottom, buried or submerged steel structure, etc.
Description
—— Functions ——
- Rectifier Module: Thyristor / High Frequency Switch / Silicon Rectifier
- Mode Switch: Auto / Manual(25-step outputs)
- Touch Screen Panel
- LED Digital Display
- Timing Interruption Program
- Surge Protection
- Lightning Protection (optional)
- Sun Protection (optional)
- Data Remote Transmission and Control (optional)
- GPS Synchronization Current Interrupter (optional)
—— Working Environment ——
Temperature: 15°C ~ 50°C
Humidity: 15% ~ 90% RH
Air Pressure: 86kPa ~ 106kPa
Parameters
| Category | Air Cooled Transformer Rectifier |
|---|---|
| Power Input | AC 220V, AC 380V |
| Output Voltage | DC 100V, 50A |
| Insulation Resistance | >10mΩ |
| Control Range | -3V~3V |
| Control Accuracy | 10mV |
| Noise | < 80dB |
| IP Level | IP44, IP66 |
| Lifetime | 30 yrs. |
