Bolted Magnesium Condenser Anode (Square Shape)
YUXI manufactures a full product line of magnesium anode slabs and blocks, suitable for use in heat exchangers, condenser water boxes, cooling towers, intercoolers and tank interiors. Our condenser anode is available as either bare or plastisol coated. The plastisol (polyvinyl chloride) coating on the sides, ends, and faying surfaces serves as an excellent current barrier shield.
Description
—— Chemical Composition ——
Our magnesium anode is produced using H-1 Grade C (commonly known as H1C) alloy ingots, conforming to ASTM B843-AZ63B standard.
—— Electrochemical Properties ——
With an open circuit potential of negative 1.5 volts w.r.t. Cu/CuSO4 reference electrode, our aqueous magnesium anodes are normally used in fresh water applications.
Parameters
| Category | Condenser Anode |
|---|---|
| Substrate | Magnesium Alloy |
| Shape | Square |
| Applicable Environment | Fresh Water |
| Application | Condenser |
| Certification | ABS |
Specification
Specification
Note: All dimensions and weights shown above are nominal. The information provided is subject to change without notice.
