Magnesium Ribbon Anode
As a flexible anode material, magnesium ribbon anode consists of an extruded ribbon of magnesium around a central continuous galvanised steel core which ensures a uniform current and efficient electrical discharge. Due to larger area-to-mass ratio, magnesium ribbon anode can provide higher current outputs when compared to other magnesium anodes.
Description
—— Chemical Composition ——
Our magnesium ribbon anode is produced using high purity ingots, conforming to ASTM B843-M1C standards.
—— Electrochemical Properties ——
With a high driving potential of -1.7V to -1.75V (CSE), it can generate more current than their cast magnesium counterparts. Generally, the current output is three to seven times greater than cast anodes of the same weight.
—— Practical Application ——
The magnesium ribbon anode is easy to bend and has a small footprint — particularly used in areas of restricted space. It is applied to coil the protected body, especially in cathodic protection engineering of long-distance pipelines, crossing pipe sections, pipelines in casings (inner pipe of drive pipe), internal protection of huge tank or silo, grounding protection against strong electrical interference and so on. It runs automatically after installation — no maintenance required. Moreover, it does not cause any interference with the external environment.
Parameters
| Category | Ribbon Anode |
|---|---|
| Substrate | Magnesium Alloy |
| Shape | Ribbon |
| Applicable Environment | Sand, Soil |
| Application | Pipeline |
| Certification | ABS |
Specification
Specification
Note: All dimensions and weights shown above are nominal. The information provided is subject to change without notice.
