This continuous cable-like anode is an integrated auxiliary anode composed of a copper wire and a conductive polymer sheath. The copper core serves as a low resistance bus bar to deliver the required current over considerable distance without incurring substantial longitudinal voltage drop. And the extruded polymer layer seals the copper wire from chemical attack.
—— Quality Copper Conductor ——
Our power cable delivers the required current over considerable distance without incurring substantial longitudinal voltage drop. The choice of the cable can be made from HMWPE, XLPE/PVC, Kynar/HMWPE or as per specification.
—— Evenly Backfill Filling ——
—— Acid-resistant Braid Fabric Jacket ——
—— Reel Packing ——
Our polymer linear anode can be packed on wooden or steel reel as required. It is normally installed right from the factory provided reel into the trench for easy transportation.
—— Practical Application ——
The anode is generally located in close proximity to the structure to be protected, and provides uniform cathodic protection current to the entire structure. It is ideal for use in all kind of soil, especially well suited the environment where the resistivity is high or various.
| Category | Flexible Linear Anode |
|---|---|
| Cable Type | HMWPE |
| Fill Material | Calcined Petroleum Carbon Backfill |
| Sock Material | Non-woven Fabric |
| Braiding Material | Polypropylene Filament |
| Working Temperature | Min. -18°C (0°F) |
| Applicable Environment | Sand, Soil |
| Application | Aboveground Tank, Pipeline |
Product datasheet including basic product information, technical data, instructions for use and size options.
